Flagship model among the padel courts available on the market. Groundbreaking design without deviating in regards to current normative.

Elaborated for the practicing of the Padel Sport, including at the highest level following the corresponding norms and regulations (NIDE 2004 Padel), regulations and norms of the F.E.P. (Spanish Padel Federation) and structural calculations based on the official Technical Building Code (TBC).

Padel courts characteristics

All the padel court models designed and developed by Euronix have been elaborated for the practicing of padel, including at the highest level following the corresponding norms and regulations (NIDE 2004 Padel), regulations and norms of the F.E.P. (Spanish Padel Federation) and structural calculations based on the official Technical Building Code (TBC).

As an introduction, the general characteristics and distinguishing properties of the padel courts can be short summarized as follows:

• Padel court produced using high quality material.
• High resistance and strength of the padel court installation.
• Durability of the installation.
• Quality and aesthetics enabling a perfect architectonic combination with the surroundings.

The minimalistic design provides a genuine perception of harmony and beauty without deviating in regards to current normative.

Padel court manufacturing

The structural system of the padel court is composed of 26 support posts, each of which is resting on an individual ground socket plate and with reinforcing support plates.

The height of the posts vary between 3,4 and 6 meters and are equipped with angle profiles and corresponding fixing plates for the she secure tightening of the surrounding closure walls, composed by either tempered glass or steel framed wire mesh.

The Steel closure of the padel court is made from frames of steel profiles, type PDS-26. The shape obtained through cold rolling process gives it a perfect geometry for the fixing of the electro-welded wire mesh as it is placed on the small flange edge of the profile.

As glass closure we use 14 tempered glass units of 3000×2000 mm y 4 units of 2000×2000 mm with thickness 10 or 12 mm following customer requirements.

These units are equipped with regulation system for adjustment and come with rounded edges for the glass closure and steel closure to be fixed precisely at the same vertical level.

The fabrication process of the tempered glass is normalized and conforms to the norm UNE EN 12150-1.

The contact points between the tempered glass plates and the steel material are the most delicate places on the padel court, and for this reason we give special care and attention when designing and choosing the material to be used as neoprene, which gives excellent properties of the material, durability and long lifetime even in adverse weather conditions.
